Engine Cable Harness, Body Mounted for 2003 Mercedes-Benz S430
No.
Part # / Description / Price
Price
10
Electric Line
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Engine cable harness,body mounted.
10
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Engine cable harness,body mounted. Engine compartment.
50
Holder Mercedes-Benz
Mercedes-Benz Description: Right front axle electrical distributor x62/6. 7-pin. Plug connection front axle,left and right. 7-pin.
50
Holder Mercedes-Benz
Mercedes-Benz Description: Right front axle electrical distributor x62/6. 2-pin (7-pin layout). Plug connection front axle,left and right. 2-pin (7-pin layout). To 036 545 15 28. 2-pin (7-pin layout).
MSRP $4.00
$3.05
MSRP $4.00
$3.05
60
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Front axle distributor connector left x62/7. Plug connection front axle,left and right to 002 545 17 40.
60
Clutch Housing Mercedes-Benz
Mercedes-Benz Description: Front axle distributor connector left x62/7. Plug connection front axle,left and right.
90
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Headlight leveling sys. Signal acquisition and actuation module n10/6. 20 pin mqs.
100
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Engine control module cod. B. 40-pin. Engine control module. 40-pin.
100
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Mqs. Control unit. 40-pin. Common-rail control module n39/2,. 40-pin. Engine control module cod. A. 40-pin. Engine control module n3/9. 40-pin.
100
Cap Mercedes-Benz
Mercedes-Benz Description: Engine control module. Pin bushing housing to 001 545 77 40. Plug housing to 001 545 83 40. Me. Control unit.
120
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Front axle distributor in maj. Ass. Comp. Brake wear indicator x62/7. 2 pin mqs
model 1: mqs
slots: 2. Pressure converter exhaust gas recirculation. 2 pin mqs
model 1: mqs
slots: 2. Brake lining wear indicator plugconnection,rear x88/15. 2 pin mqs
model 1: mqs
slots: 2. Coolant level s41. 2 pin mqs
model 1: mqs
slots: 2.
model 1: mqs
slots: 2. Pressure converter exhaust gas recirculation. 2 pin mqs
model 1: mqs
slots: 2. Brake lining wear indicator plugconnection,rear x88/15. 2 pin mqs
model 1: mqs
slots: 2. Coolant level s41. 2 pin mqs
model 1: mqs
slots: 2.
MSRP $5.75
$4.32
MSRP $5.75
$4.32
130
Plug Mercedes-Benz
Mercedes-Benz Description: To susp. Front axle shock absorbers b22/4, b22/5. Plun. Trav. Sen. Left and right front.
MSRP $7.00
$5.33
MSRP $7.00
$5.33
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: AIR CONDITIONING MULTIFUNCTION SENSOR B31/1. 0.5 MM2 MQSLeitungsquerschnitt Min/Max: 0,5mm2Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Belt locking retractor plug-connection x28/8. X28/9. 0.5 MM2 MQSLeitungsquerschnitt Min/Max ...
MSRP $7.75
$5.84
MSRP $7.75
$5.84
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 0.75 MM2 MQS
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Repair solution contacting 0,75 mm2. MQS. 0.75 MM2 MQS
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $7.75
$5.84
MSRP $7.75
$5.84
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $8.00
$5.97
MSRP $8.00
$5.97
176
Contact Insert Mercedes-Benz
Mercedes-Benz Description: 8.0 - 12.0 MM2. 8.0-12.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-12,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LSK
Model 2: 8. M4/7_A. 8.0-12.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-12,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LSK
Model 2: 8.
Leitungsquerschnitt Min/Max: 8,0-12,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LSK
Model 2: 8. M4/7_A. 8.0-12.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-12,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LSK
Model 2: 8.
178
Gasket Mercedes-Benz
Mercedes-Benz Description: BLACK 4.5-6.2 MM. 4.5-6.2 MM2 LSK8
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. 6.0 MM2. 4.5-6.2 MM2 LSK8
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. 6.0 MM2. 4.5-6.2 MM2 LSK8
Leitungsquerschnitt Min/Max: 4,5mm2-6,2mm2
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
MSRP $4.70
$3.56
MSRP $4.70
$3.56
178
Seal Mercedes-Benz
Mercedes-Benz Description: Induction throttle valve abs susp. Y86/1. 4.0 MM MLK1.2/LKS1.5Leitungsquerschnitt Min/Max: 4,0mm2ELA: +Model 1: MLK1.2/LKSModel 2: 1.5Release tool: W220 589 01 99 25Crimp tool: W220 589 01 99 84. FRONT VALVE UNIT Y36/1. 4.0 MM MLK1.2/LKS1.5Leitungsquerschn ...
MSRP $1.10
$0.79
MSRP $1.10
$0.79
190
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Lowith high pressure switch connection. 3-pin jpt. Pressure sensor. 3-pin jpt.
MSRP $7.25
$5.46
MSRP $7.25
$5.46
200
Plug Mercedes-Benz
Mercedes-Benz Description: Control for electric suction-type fan. 7-pin. Control module,auxiliary fan 7 polig. 7-pin. Electric suction-type fan control module engine / a/c. 7-pin. Suction cooling fan. 7-pin.
205
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Fan motor m4/7. 4-pin slk2.8, lsk8. Cooler fan 4-pin m4/7. 4-pin slk2.8, lsk8. Fan motor n76. 4-pin slk2.8, lsk8. Electric suction-type fan control module engine / a/c n76. 4-pin slk2.8, lsk8. Fan motor n65/1. 4-pin slk2.8, lsk8. Ac blower control unit box n65/2. 4-pin slk2.8, lsk8. Auxiliary fan. 4-pin slk2.8, lsk8. M4/3. 4-pin slk2.8, lsk8. Cooler blower m4/7_a. 4-pin slk2.8, lsk8.
MSRP $9.25
$6.99
MSRP $9.25
$6.99
215
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Regeneration valve y58/1. Compressor. Change-over valve 2 polig, (frischluft/umluft). Shutoff valve activated-carbon filter. Change-over valve activated charcoal filter. Control switch, fresh air/air circulation.
220
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Intermediate conn. Wheel arch fan motor A27/1. 2-PIN SLK2.8
Model 1: SLK
Model 2: 2.8
Slots: 2
Release tool: W220 589 01 99 62. FAN MOTOR OIL M4/1. 2-PIN SLK2.8
Model 1: SLK
Model 2: 2.8
Slots: 2
Release tool: W220 589 01 99 62. Control unit, auxilliary heater. 2-pin slk2.8
model 1: slk
model 2: 2.8
slots: 2
release tool: w220 589 01 99 62.
Model 1: SLK
Model 2: 2.8
Slots: 2
Release tool: W220 589 01 99 62. FAN MOTOR OIL M4/1. 2-PIN SLK2.8
Model 1: SLK
Model 2: 2.8
Slots: 2
Release tool: W220 589 01 99 62. Control unit, auxilliary heater. 2-pin slk2.8
model 1: slk
model 2: 2.8
slots: 2
release tool: w220 589 01 99 62.
230
Plug Mercedes-Benz
Mercedes-Benz Description: Speed-sensitive steering valve Y10. 2-PIN SLK2.8
Model 1: SLK
Model 2: 2.8
Slots: 2
Release tool: W220 589 01 99 62. Shutoff valve activated-carbon filter y58. 2-pin slk2.8
model 1: slk
model 2: 2.8
slots: 2
release tool: w220 589 01 99 62.
Model 1: SLK
Model 2: 2.8
Slots: 2
Release tool: W220 589 01 99 62. Shutoff valve activated-carbon filter y58. 2-pin slk2.8
model 1: slk
model 2: 2.8
slots: 2
release tool: w220 589 01 99 62.
MSRP $4.70
$3.56
MSRP $4.70
$3.56
245
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: With seal. 1.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30. WINDOW REGULATOR,LEFT (M10/5). 1.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30. WINDOW REGULATOR,LEFT (M10/5). 1.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
MSRP $12.50
$9.40
MSRP $12.50
$9.40
245
Electric Line Mercedes-Benz
Mercedes-Benz Description: 2.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
MSRP $11.00
$8.38
MSRP $11.00
$8.38
250
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Brake lamp e3/5, e4/5. 2-pin mcp2.8. Washer fluid pump headlamps 2-pin m5/2. 2-pin mcp2.8.
MSRP $4.70
$3.56
MSRP $4.70
$3.56
260
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Rear heater system delivery unit a31/1. 3-pin;slk2.8. Left lighting unit e1. 3-pin;slk2.8. Lighting unit e1 e2. 3-pin;slk2.8. Delivery unit heating. 3-pin;slk2.8. Right front lamp unit E1,E2,CODE A. 3-PIN;SLK2.8. Lamp unit left and right e1/e2. 3-pin;slk2.8.
MSRP $6.00
$4.45
MSRP $6.00
$4.45
280
Electrical Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. With single-wire seal. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. With single-wire seal. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
MSRP $9.75
$7.37
MSRP $9.75
$7.37
290
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Door lock a85,a85/1. 6-pin slk2.8. Door lock a85/3,a85/4. 6-pin slk2.8. Lamp unit left and right e1,e2. 6-pin slk2.8. Lighting unit E1. 6-PIN SLK2.8.
MSRP $5.50
$4.19
MSRP $5.50
$4.19
300
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.50
$5.66
MSRP $7.50
$5.66
310
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: ITT ESP® hydraulic unit A7/3. 15-PIN RK2.5. Hydraulic unit asr/ets. 15-pin rk2.5.
MSRP $18.50
$13.97
MSRP $18.50
$13.97
330
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 1.0 mm2.
MSRP $8.00
$5.97
MSRP $8.00
$5.97
330
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 2.5 MM2
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: Sn
Model 1: DIA
Model 2: 2.5.
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: Sn
Model 1: DIA
Model 2: 2.5.
330
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 4.0 MM2
Leitungsquerschnitt Min/Max: 4mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 2: 2,5mm.
Leitungsquerschnitt Min/Max: 4mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 2: 2,5mm.
MSRP $10.50
$8.00
MSRP $10.50
$8.00
360
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Connector, heated windshield x92/6. 2-pin lsk8
model 1: lsk
model 2: 8
slots: 2. Suction-type fan connector. 2-pin lsk8
model 1: lsk
model 2: 8
slots: 2. Fan motor n4/3. 2-pin lsk8
model 1: lsk
model 2: 8
slots: 2.
model 1: lsk
model 2: 8
slots: 2. Suction-type fan connector. 2-pin lsk8
model 1: lsk
model 2: 8
slots: 2. Fan motor n4/3. 2-pin lsk8
model 1: lsk
model 2: 8
slots: 2.
370
Electric Line Mercedes-Benz
Mercedes-Benz Description: FAN MOTOR M4/3. 6.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 6,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. FLAT PLUG 4.0 - 6.0 MM2. 6.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 6,0mm2Oberflächenschutz PINs: AgModel ...
MSRP $18.50
$13.97
MSRP $18.50
$13.97
370
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: X64/7. 4.0 MM2 LSK8 AG
Leitungsquerschnitt Min/Max: 4,0mm2
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
Leitungsquerschnitt Min/Max: 4,0mm2
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
MSRP $20.00
$15.24
MSRP $20.00
$15.24
380
Socket-Outlet Mercedes-Benz
Mercedes-Benz Description: Engine hood switch anti-theft alarm system. 2-pin. Engine hood contact switch 2-polig. 2-pin.
390
Round Receptacle Mercedes-Benz
Mercedes-Benz Description: 1MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. 1,0 MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. DATA LI ...
MSRP $8.25
$6.22
MSRP $8.25
$6.22
400
Plug Mercedes-Benz
Mercedes-Benz Description: Left 02 probe upstream of cat. G3/3. Oxygen sensor,black. Oxygen sensor downstream of catalytic converter g3/5. 02 sensor in front of catalytic converter 4-pin. Diagnosis probe. Oxygen sensor plug connection. Fuel delivery pump control unit n118.
MSRP $10.00
$7.49
MSRP $10.00
$7.49
410
MSRP $3.20
$2.41
440
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Signal acq. & actuation mod. (sam) n10/6, n10/7. 6-pin slk2.8. Combination switch. 6-pin slk2.8. N28/1. Trailer control unit. Connector: 4. 6-pin slk2.8. Steering column adjustment up/down black. 6-pin slk2.8. Control unit. 6-pin slk2.8. Electrical center. 6-pin slk2.8. Signal acquisition and actuation module n10/7. 6-pin slk2.8.
450
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, front passenger k40/4, mr1. 10-pin. Electrical center. 10-pin. Fuse and relay module, rear f4 (p1). 10-pin. Relay unit f58. 10-pin. Fuse and relay box, front passenger,transparent. 10-pin.
MSRP $4.20
$3.18
MSRP $4.20
$3.18
470
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: With single-wire seal. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62. SOUND AMPLIFIER N40/3,N93/1. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PIN ...
470
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
MSRP $11.50
$8.62
MSRP $11.50
$8.62
470
Contact Spring Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
MSRP $5.00
$3.81
MSRP $5.00
$3.81
480
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Body controller n10/6. 2-pin. Fuse and relay module, driver k40/2, m3. 2-pin. Black n10/6. 2-pin. Electrical center. 2-pin. Control module sam/srb rear n10/8, cod. a. 2-pin.
MSRP $12.00
$9.02
MSRP $12.00
$9.02
500
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: JPT
Model 1: JPT
Model 2: 2.8
Slots: 8. Control unit. 8-pin. Engine control module n3/9. 8-pin. Engine control module 8-polig. 8-pin.
Model 1: JPT
Model 2: 2.8
Slots: 8. Control unit. 8-pin. Engine control module n3/9. 8-pin. Engine control module 8-polig. 8-pin.
520
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Silver-plated. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. Central electrics in eng. COMPARTMENT LEFT FRONT N10/1. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Obe ...
MSRP $12.00
$9.02
MSRP $12.00
$9.02
530
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Connector for transceiver part x39/5. 10-pin. Connector cockpit/frame floor system x18/35. 10-pin. Air conditioner cable harness plugconnection. 10-pin. Transceiver connector, black x39/5. 10-pin. Breakdown/information button conn. X39/48. 10-pin. Tail lamp cable harness plugconnection. 10-pin.
540
Plug Mercedes-Benz
Mercedes-Benz Description: To 168 545 09 40. Breakdown/information button conn.
MSRP $7.00
$5.21
MSRP $7.00
$5.21
560
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$5.33
MSRP $7.00
$5.33
570
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Wiper motor. 4-pin spt. Pneumatic control unit. 4-pin spt. Airbag, passenger side. 4-pin spt. Door separation point,a-pillar. 4-pin spt. Electrical center. 4-pin spt. Relay. 4-pin spt.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
580
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
585
Fuse Box Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. L26. Natural-colored. Dual, left l4/11-12. Plug position: l4/l8 k40/2.
585
Fuse Box Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. Fuse and relay module, rear k40/5. Double l29/55-56. 2-slot. Dual, left l2/8-9. 2-slot. 2-speed (f4). 2-slot. Black. 2-slot. Fuse box left. 2-slot. Fuse and relay box,driver k40/2. 2-slot. L29/l41/l42 k40/5. 2-slot.
610
Locking Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Wiper park position heater separation point in major assemblies compartment. For plug wiper rest heater in maj. Assemblies compartment right. Heater for wiper rest position.
620
Protective Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Covering cap for socket housing (pump-headlamp cleaning system).
620
Protective Cap Mercedes-Benz
Mercedes-Benz Description: Connecting point splithoff identification lamp x7/1. Intermediate connector roof sign lamp x40. Washer nozzle hose heating.
700
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Bracket to left wheel arch panel. Trimmer plug.
710
715
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Main muffler suspension. M8x16. Central muffler suspension. Bracket on rear axle m 8x16.
MSRP $3.20
$2.41
MSRP $3.20
$2.41
770
Holder Mercedes-Benz
Mercedes-Benz Description: At bracket. 24x23 mm. Oxygen sensor lead mounting. 24x23 mm. Lambda probe left plug connector. 24x23 mm. At transmission,rear. 24x23 mm. Plug pump control device. 24x23 mm. Control probe. 24x23 mm.
MSRP $13.50
$10.16
MSRP $13.50
$10.16
